| 主营： | 动力电池充电器 | |
|---|---|---|
| 企业： | 未核实 | |
|
||
联系人：徐东 电 话：86-0510-85386718
手 机：15052286818 （打电话的时，请说中国电动车网看到的） 传 真：--
地 址：无锡新区新安镇沙敦港工业区
发布日期: 2014年8月30日 有效期至 2015年8月25日
- 产品描述
- 我要留言
| 技术参数 | |||||||||||
| key parameters | |||||||||||
| 序号SerialNo. | 系列规格Specifications | 充电恒压（限压：V）Constant Voltage of Charging (Voltage Limiting:V) | 充电恒流Constant Current of Charging | 转换/关断Switch/Turn-off | 适用电池容量 Battery Capacity | 产品尺寸(mm) Size(mm) | 毛重 Gross Weight | ||||
| 铅酸Lead-acid | 锰锂Lithium Manganese | 鉄锂Lithium Iron | 限流（A）Current Limiting(A) | 铅酸（A）Lead-acid (A) | 锂电（A）Lithium-ion (A) | ||||||
| 加水型Liquid-adding | 免维护型Maintenance-free | ||||||||||
| 1 | VC2408 | 32.4 | 29.4 | 29.4 | 29.2 | 8.0 | 1.6 | 0.8 | 7串鉄锂或锰锂电池seven lithium iron or lithium manganese batteries | 190*95*55mm | 1.5KG |
| 2 | VC3606 | 48.6 | 44.1 | 42.0 | 43.8 | 6.0 | 1.2 | 0.6 | 10串鉄锂或锰锂电池ten lithium iron or lithium manganese batteries | ||
| 3 | VC4805 | 64.8 | 58.8 | 54.6 | 58.4 | 5.0 | 0.8 | 0.4 | 13串鉄锂或锰锂电池thirteen lithium iron or lithium manganese batteries | ||
| 4 | VC6003 | 81.0 | 73.5 | 75.6 | 73.0 | 3.0 | 0.6 | 0.3 | 18串鉄锂或锰锂电池eighteen lithium iron or lithium manganese batteries | ||
| 功能特性 Features *预充,恒流，恒压，三段式锂电充电模式，预充,恒流，恒压涓流，浮充，五段式铅酸电池充电模式，适合各大电池厂家建议的充电曲线，特殊要求可根据客户定制。； Pre-charge, constant current, constant voltage three-stage lithium ion charging mode and pre-charge, constant current, constant voltage, trickle, floating five-stage lead-acid charging mode are suitable for charging curve recommended by major battery manufaturers. Chargers can be custom-made in accordance with special requirements of customers. *电池故障保护功能：接通电池与充电过程中，实时监测电池状态，电池故障或电池型号不对时，进入电池故障保护； Battery failure protection function：in the process of battery being connected and charging, battery status is monitored. When battery failure or battery model is not right ,battery failure protection starts; *反接保护功能：充电机输出与电池极性接错时，进入反接保护； Reverse connection protection function: the temperature of the charge is too high because of special reasons(for example, the fan is blocked; heat emission holes are covers), protection function starts; *过热保护功能：特殊原因导致充电机内温度过高（如风机堵死，散热孔遮挡），进入过热保护功能； Overheating protection function: the temperature of the charger is too high because of special reasons(for example, the fan is blocked; heat emission holes are covers), protection function starts; *温度补偿功能：恒压电压点与浮充电压点设置温度补偿，吻合电池的负温度系数特性（-4Mv/℃）； Temperature compensation function: temperature compensation is set up at constant voltage point and floating voltage point to match negative Temperature Coefficient of battery（-4Mv/℃）； *特色待机功能：接通电源后，长时间不接电池或电池充满后长时间不断开电源，进入特色待机状态。 Special standby function: after power source is connected, battery is not connected for a long time or the power source is not disconnected after the battery is full, special standby function starts. | |||||||||||
